Commissioning
Configuring the host system (master)
6
l
34 EDSMF2133IB EN 5.0
6.3 Configuring the host system (master)
The host must be configured before communication with the communication module is
possible.
Master settings
For configuring the PROFIBUS, the device data base file (GSE file) of the communication
module has to be imported into the configuring software of the master.
I
Tip!
The GSE file can be downloaded in the "Services & Downloads" area at
www.Lenze.com.
Device data base file (GSE)
The following configurations can be found in the device data base files Lenz2133.GSD
(DP−V0) and Len_2133.GSD (DP−V1):
ƒ Device control and DP−V0 parameter data channel
Selection text in Lenz2133.GSE Parameter data Process data Assigned I/O
memory
without
consistency with consistency without
consistency with consistency
PAR(cons.)+PZD(nwordsI/O)AR
·
n words 4 + n words
PAR(cons.)+PZD(nwordscon)AR n words 4 + n words
PAR + PZD(n words I/O) AR
·
n words 4 + n words
PAR + PZD(n words con) AR n words 4 + n words
PZD(n words I/O) AR
Without parameter data channel
n words n words
PZD(n words cons.) AR n words n words
n = 1 ... 12
ƒ DRIVECOM control and DP−V0 parameter data channels
Selection text in Lenz2133.GSE Parameter data Process data Assigned I/O
memory
without
consistency with consistency without
consistency with consistency
PAR(cons.) + PZD(n words I/O)
·
n words 4 + n words
PAR(cons.) + PZD(n words cons.) n words 4 + n words
PAR + PZD(n words I/O)
·
n words 4 + n words
PAR + PZD(n words cons.) n words 4 + n words
PZD(n words I/O)
Without parameter data channel
n words n words
PZD(n words cons.) n words n words
n = 1 ... 12
