Commissioning
Configuring the host system (master)
6
l
35 EDSMF2133IB EN 5.0
ƒ POFIdrive control and DP−V1 parameter data channel
Selection text in Len_2133.GSE Parameter data Process data Assigned I/O
memory
without
consistency with consistency without
consistency with consistency
PPO1
·
2 words 6 words
PPO2 6 words 10 words
PPO5 10 words 14 words
PPO3
Without parameter data channel
2 words 2 words
PPO4 6 words 6 words
PPO1 (process data consistency)
·
2 words 6 words
PPO2 (process data consistency) 6 words 10 words
PPO5 (process data consistency) 10 words 14 words
PPO3 (process data consistency)
Without parameter data channel
2 words 2 words
PPO4 (process data consistency) 6 words 6 words
n = 1 ... 12
Example of the selection text of the device data base file
PAR (Cons) + PCD (7W) AR
Lenze device control
Process data words
(7 words)
Parameter data channel
(4 bytes consistent)
PAR (Cons) + PCD (8W)
Without "AR": Control with DRIVECOM−Profil
Process data words
(8 words)
Parameter data channel
(4 bytes consistent)
)
Note!
Use overall consistency
ƒ We recommend to exclusively use configurations with consistency for the
parameter data channel to avoid data conflicts between the PROFIBUS
master and the host CPU.
ƒ Please note that the processing of consistent data varies between hosts.
This must be considered in the PROFIBUS application program.
ƒ Detailed information on consistency can be found on
^ 110.
