Process data transfer
Lenze device control
Process data signals for 82XX frequency inverters
7
l
50 EDSMF2133IB EN 5.0
Device control word AIF−CTRL for 82XX (C0135, index 5F78
hex
)
820X 821X / 822X / 824X
Bit Assignment Bit Assignment
0 / 1 JOG values 0 / 1 JOG values
Bit 1 0 Bit 1 0
0 0 C0046 active 0 0 C0046 active
0 1 JOG1 in C0037 active 0 1 JOG1 in C0037 active
1 0 JOG2 in C0038 active 1 0 JOG2 in C0038 active
1 1 JOG3 in C0039 active 1 1 JOG3 in C0039 active
2 CW/CCW rotation 2 CW/CCW rotation
0
1 CW rotation
CCW rotation 0
1 CW rotation
CCW rotation
3 Quick stop (QSP) 3 Quick stop (QSP)
0
1 QSP not active
QSP active 0
1 QSP not active
QSP active
4 ... 8 Reserved 4 Ramp function generator (RFG) stop
0
1 RFG stop not active
RFG stop active
5 Ramp function generator (RFG) zero
(Deceleration on the T
if
ramp C0013)
0
1 RFG zero not active
RFG zero active
6 UP function for motor potentiometer
0
1 UP not active
UP active
7 DOWN function for motor potentiometer
0
1 DOWN not active
DOWN active
8 Reserved
9 Controller inhibit (CINH)) 9 Controller inhibit (CINH))
0
1 Not active
Active 0
1 Not active
Active
10 Reserved 10 Reserved
11 Reserved 11 TRIP reset
0 −> 1: Edge from 0 to 1
12 PAR1 (parameter set changeover) 12 PAR1 (parameter set changeover)
0 −> 1: Parameter set
1 −> 0: Parameter set 0 −> 1: Parameter set
1 −> 0: Parameter set
13 Reserved 13 Reserved
14 DC injection brake 14 DC injection brake
0
1 DC brake not active
DC brake active 0
1 DC brake not active
DC brake active
15 Reserved 15 Reserved
