Process data transfer
Lenze device control
Process data signals for 82XX frequency inverters
l
47
EDSMF2133IB EN 5.0
7.1.2
Process data signals for 82XX frequency inverters
Process data telegram from drive
Byte 1
Byte 2
Byte 3
Byte 4
Status word
Actual value
High byte
Low byte
High byte
Low byte
)
Note!
ƒ
Frequency and speed values are scaled with
"24000 5 "480 Hz.
ƒ
Torque values are scaled with 16384
5 100%.
