Process data transfer
Lenze device control
Process data signals for 8200 vector frequency inverters
l
55
EDSMF2133IB EN 5.0
Device control word AIF−CTRL for 8200 vector (C0135, index 5F78
hex
)
Bit
Assignment (Lenze setting)
Set under
C0410/...
C0001 = 3 with C0007
£ 51
C0001 = 3 with C0007 > 51
0 / 1
JOG values
Freely configurable
1
2
Bit 1
0
0
0
00 = C0046 active
0
1
01 = NSET1−JOG1 (C0037) active
1
0
10 = NSET1−JOG2 (C0038) active
1
1
11 = NSET1−JOG3 (C0039) active
2
Current direction of rotation
(DCTRL1−CW/CCW)
Freely configurable
3
0
1
Not active
Active
3
Quick stop (QSP)
(AIF−CTRL−QSP)
Quick stop (QSP)
(AIF−CTRL−QSP)
4
0
1
Not active
Active
0
1
Not active
Active
4
Stop ramp function generator
(NSET1−RFG1−STOP)
Freely configurable
5
0
1
Not active
Active
5
Ramp function generator input = 0
(NSET1−RFG1−0)
Freely configurable
6
0
1
Not active
Active
6
UP function motor potentiometer
(MPOT1−UP)
Freely configurable
7
0
1
Not active
Active
7
DOWN function motor potentiometer
(MPOT1−DOWN)
Freely configurable
8
8
Freely configurable
Freely configurable
9
9
Controller inhibit
(AIF−CTRL−CINH)
Controller inhibit
(AIF−CTRL−CINH)
10
0
1
Not active
Active
0
1
Not active
Active
10
External fault
(AIF−CTRL−TRIP−SET)
External fault
(AIF−CTRL−TRIP−SET)
11
0
1
Not active
Active
0
1
Not active
Active
11
Reset fault
(AIF−CTRL−TRIP−RESET)
Reset fault
(AIF−CTRL−TRIP−RESET)
12
0 −> 1 Edge from 0 to 1
0 −> 1 Edge from 0 to 1
12
Change over parameter set
(DCTRL1−PAR2/4)
Freely configurable
13
0
1
Not active
Active
13
Change over parameter set
(DCTRL1−PAR3/4)
Freely configurable
14
0
1
Not active
Active
14
DC injection brake
(MCTRL1−DCB)
Freely configurable
15
0
1
Not active
Active
15
Freely configurable
Freely configurable
