Appendix
Parallel operation of AIF and FIF interfaces
12
l
127 EDSMF2133IB EN 5.0
Possible combinations
Function module on FIF
(Design: Standard or PT) Communication module on AIF
Keypad E82ZBC 1)
Keypad XT EMZ9371BC 1)
PROFIBUS−DP 2131/2133
Standard I/O E82ZAFS ьь ьь
Application I/O E82ZAFA ьь ь
INTERBUS E82ZAFI üü x
PROFIBUS−DP E82ZAFP üü X
LECOM−B (RS485) E82ZAFL üü X
System bus (CAN)
System bus I/O RS
System bus I/O E82ZAFC
E82ZAFC100
E82ZAFC200
ьь ьь
CANopen /
DeviceNet
2)
E82ZAFD üü X
ASI E82ZAFF üü X
1) Is always supplied via internal voltage source regardless of the jumper setting.
2) In preparation
üü Combination possible, communication module is supplied internally or externally.
üü Combination possible, communication module must be supplied externally
( ü ) Combination possible, communication module can only be used for parameter setting (supplied internally or
externally).
x Combination not possible.
