Commissioning

Setting the node address

Settings by a master (class 2)

6

l

43

EDSMF2133IB EN 5.0

6.7.3

Settings by a master (class 2)

ƒ

With this method only one device must be connected to the bus. This can be
achieved by a special switch−on sequence.

ƒ

In the "Power On" status, the master (class 2) can set a device address via the
"Set_Slave_Address" telegram.

ƒ

Settings made through the master (class 2 only) have an effect on the setting in
standard device code C0009.

PROFIBUS station address

Mapping to code C0009

1 ... 2

No (master addresses)

3 ... 99

Yes (3 ... 99)

100 ... 125

Yes (C0009 = 2)

126 (LENZE setting)

Yes (C0009 = 1)

Tab. 6−1

Assignment of station addresses to controllers
