Parameter data transfer
PROFIdrive parameter data channel
PROFIdrive DP−V1
8
l
102 EDSMF2133IB EN 5.0
Parameter value
Depending on the data type, the user data are assigned as follows:
Data type Length
Assignment of the user data
Byte 7 Byte 8 Byte 9 Byte 10 Byte ...
String x bytes
U8 1 byte 00
High byte Low byte
U16 2 bytes
High word Low word
High byte Low byte High byte Low byte
U32 4 bytes
(This representation applies to one parameter value.)
