Process data transfer

Lenze device control
Process data signals for 82XX frequency inverters

7

l

48

EDSMF2133IB EN 5.0

Device status word AIF−STAT for 82XX (C0150, I−5F69)

820X

821X / 822X / 824X

Bit

Assignment

Bit

Assignment

0

Current parameter set

0

Current parameter set

0
1

Parameter set 1 or 3 active
Parameter set 2 or 4 active

0
1

Parameter set 1 or 3 active
Parameter set 2 or 4 active

1

Pulse inhibit (IMP)

1

Pulse inhibit (IMP)

0
1

Pulses for power stage enabled
Pulses for power stage inhibited

0
1

Pulses for power stage enabled
Pulses for power stage inhibited

2

I

max

(current limit reached)

2

I

max

(current limit reached)

0
1

Current limit not reached
Current limit reached

0
1

Current limit not reached
Current limit reached

3

Not assigned

3

f

d

= f

dset

0
1

f

d

¹ f

dset

f

d

= f

dset

4

f

d

= f

dset

4

Ramp function generator (RFG) on/off

0
1

f

d

¹ f

dset

f

d

= f

dset

0
1

RFG−On

¹ RFG−Off

RFG on = RFG off

5

Qmin (f

d

£ f

dQmin

)

5

Qmin

(f

d

£ f

dQmin

)

0
1

Qmin not active
Qmin active

0
1

Qmin not active
Qmin active

6

f

d

= 0

(actual frequency value = 0)

6

f

d

= 0

(actual frequency value = 0)

0
1

f

d

¹ 0

f

d

= 0

0
1

f

d

¹ 0

f

d

= 0

7

Controller inhibit (CINH))

7

Controller inhibit (CINH))

0
1

No controller inhibit
Controller inhibit active

0
1

No controller inhibit
Controller inhibit active

8 ... 11

Device status

8 ... 11

Device status

Bit

11

10

9

8

Bit

11

10

9

8

0

0

0

0

Device initialisation

0

0

0

0

Device initialisation

1

0

0

0

Active fault

0

0

1

0

Switch−on inhibit

0

0

1

1

Operation inhibited

0

1

0

0

Flying restart circuit active

0

1

0

1

DC injection brake active

0

1

1

0

Operation enabled

0

1

1

1

Message active

1

0

0

0

Active fault

1

1

1

1

Communication with standard
device not possible

12

Overtemperature warning

12

Overtemperature warning

0
1

No warning
Warning

0
1

No warning
Warning

13

U

Gmax

(DC bus overvoltage)

13

U

Gmax

(DC bus overvoltage)

0
1

No overvoltage
Overvoltage

0
1

No overvoltage
Overvoltage

14

Direction of rotation

14

Direction of rotation

0
1

CW rotation
CCW rotation

0
1

CW rotation
CCW rotation

15

Ready for operation

15

Ready for operation

0
1

Not ready for operation
Ready for operation

0
1

Not ready for operation
Ready for operation
