Process data transfer
DRIVECOM control
DRIVECOM status word
7
l
73 EDSMF2133IB EN 5.0
7.2.4 DRIVECOM status word
Bit Name Description
0 Ready to start Device status information
0 = Status lower than "READY TO START"
1 = Status at least "READY TO START"
1 Switched on Device status information
0 = Status lower than "SWITCHED ON"
1 = Status at least "SWITCHED ON"
2 Operation
enabled Device status information
0 = Status lower than "OPERATION ENABLED"
1 = Status "OPERATION ENABLED"
3 Fault Device status information
0 = No fault (TRIP)
1 = Fault (TRIP) occurred
4 Voltage
inhibited Information about command "Voltage inhibit"
0 = Command active
1 = Command not active
5 Quick stop Information about command "Quick stop" (QSP)
0 = Command (QSP) active
1 = Command (QSP) not active
6 Switch−on
inhibit Device status information
0 = Status not "SWITCH−ON INHIBIT"
1 = Status "SWITCH−ON INHIBIT"
7 Warning Collective warning
0 = No warning
1 = Warning
8 Message Group signal:
Collective message. Automatic setting and resetting of pulse inhibit (IMP) in the
device status "OPERATION ENABLED". Reasons for this can be undervoltage or
overvoltage as well as overcurrent.
0 = No message
1 = Message (IMP)
9 Remote 82xx / 821x /
822x / 8200
vector Bus access right, depending on Lenze parameter "Operating mode"
(C0001)
0 = C0001
¹ 3
1 = C0001 = 3
93XX 1
10 Setpoint
reached Status of the speed/frequency deviation
0 = RFG on
¹ RFG off
1 = RFG on = RFG off
11 Limit value Status of the DRIVECOM speed limitation is always "0".
12 Reserved 82xx / 821x /
822x Not used
8200 vector /
93XX Mapping to bit C0150.B14
13 Reserved 82xx / 821x /
822x Not used
8200 vector Mapping to bit C0150.B15
93XX Mapping to bit C0150.B3
14 Manufacturer 82xx / 821x /
822x I
max
(current limit reached)
0 = Current limit not reached
1 = Current limit exceeded
8200 vector /
93XX Mapping to bit C0150.B2
