Process data transfer
Lenze device control
Process data signals for 9300 Servo PLC and Drive PLC
7
l
63 EDSMF2133IB EN 5.0
7.1.5 Process data signals for 9300 Servo PLC and Drive PLC
Process data telegram from the drive
Name / variable name Meaning
AIF1_wDctrlStat Device status word
AIF_nOutW1_a AIF word 1
AIF_nOutW2_a AIF word 2
AIF_nOutW3_a AIF word 3
AIF2_nOutW1_a AIF word 4
AIF2_nOutW2_a AIF word 5
AIF2_nOutW3_a AIF word 6
AIF2_nOutW4_a AIF word 7
AIF3_nOutW1_a AIF word 8
AIF3_nOutW2_a AIF word 9
AIF3_nOutW3_a AIF word 10
AIF3_nOutW4_a AIF word 11
AIF1_dnOutD1_p AIF double word 1
)
Note!
9300 Servo PLC
Link the following in the PLC program of the controller:
AIF1_wDctrlCtrl
W DCTRL_wAIF1Ctrl
DCTRL_wStat W AIF1_wDctrlStat
Drive PLC
For the Drive PLC the device control must be used.
