Process data transfer
Lenze device control
Process data signals for 8200 vector frequency inverters
l
53
EDSMF2133IB EN 5.0
Device status word AIF−STAT for 8200 vector (C0150, index 5F69
hex
)
Bit
Assignment
(Lenze setting)
Set under C0417/...
0
Current parameter set
(DCTRL−PAR−B0)
1
1
Pulse inhibit
(DCTRL1−IMP)
2
2
I
max
limit
(MCTRL1−IMAX)
3
3
Output frequency = frequency setpoint
(MCTRL1−RFG1=NOUT)
4
4
Ramp function generator input = ramp function generator output 1
(NSET1−RFG1−I=0)
5
5
Q
min
threshold
(PCTRL1−QMIN)
6
6
Output frequency = 0
(DCTRL1−NOUT=0)
7
7
Controller inhibit
(DCTRL1−CINH)
8
8 ... 11
Device status
(DCTRL1−Stat*1 ... STAT*8)
Reserved
Bit 11
10
9
8
0
0
0
0
Device initialisation
0
0
1
0
Switch−on inhibit
0
0
1
1
Operation inhibited
0
1
0
0
Flying restart circuit active
0
1
0
1
DC injection brake active
0
1
1
0
Operation enabled
0
1
1
1
Message active
1
0
0
0
Fault active
1
1
1
1
Communication with basic device not possible
12
Overtemperature warning
(DCTRL1−OH−WARN)
13
13
DC−bus overvoltage
(DCTRL1−OV)
14
14
Direction of rotation
(DCTRL1−CCW)
15
15
Ready for operation
(DCTRL1−RDY)
16
AIF-OUT
AIF-STAT
16 Bit
16 Bit
.B15
.B12
.B0
.B1
.B2
.B3
.B4
.B8
.B9
.B10
.B11
16 Bit
.B13
.B14
.B5
.B6
.B7
.B0
C0417/1
AIF-OUT.W1
AIF-OUT.W2
.B1
DCTRL1-IMP
.B2
C0417/3
.B3
C0417/4
.B4
C0417/5
.B5
C0417/6
.B6
DCTRL1-NOUT=0
.B7
DCTRL1-CINH
.B8
DCTRL1-STAT*1
.B9
DCTRL1-STAT*2
.B10
.B11
DCTRL1-STAT*4
DCTRL1-STAT*8
.B12
DCTRL1-OH-WARN
.B13
DCTRL1-OV
.B14
C0417/15
.B15
C0417/16
AIF
STAT1
C0421/1
C0421/2
2141LON013
Fig. 7−4
System block AIF−OUT in 8200 vector (freely programmable assignment)
