Technical data

Communication time

Processing time 821X / 822X / 824X / 8200 vector

4

l

19

EDSMF2133IB EN 5.0

4.3.2

Processing time 821X / 822X / 824X / 8200 vector

Parameter data

Process data

30 ... 50 ms

2 ... 3 ms

4.3.3

Processing time 93XX / ECSxS

There are no interdependencies between parameter data and process data.

Parameter data

Process data

Approx. 30 ms + 20 ms tolerance (typical)
For some codes, the processing time can be longer (see
documentation for 9300 and ECS servo system).

2 ms + 1 ms tolerance

4.3.4

Processing time Drive PLC / 9300 Servo PLC / ECSxA

Parameter data

Process data

Approx. 30 ms + 20 ms tolerance (typical)
For some codes, the processing time can be longer (see
documentation for 9300 and ECS servo system).

Depending on the process image
