Process data transfer

Lenze device control

Process data signal for 9300 servo inverters

7

l

57

EDSMF2133IB EN 5.0

7.1.4

Process data signal for 9300 servo inverters

The assignment of the process data for the 93XX controller can be changed by configuring
the system blocks AIF−IN and AIF−OUT.

Process data telegram from drive

Byte 1

Byte 2

Byte 3

Byte 4

Byte 5

Byte 6

Byte 7

Byte 8

DRIVECOM status word

AIF−OUT.W1

AIF−OUT.W2

AIF−OUT.W3

High byte

Low byte

High byte

Low byte

High byte

Low byte

High byte

Low byte

Assignment of AIF−OUT.W1 ... W3 depending on the signal configuration selected under
C0005:

Signal
configuration
(C0005)

AIF−OUT.W1

AIF−OUT.W2

AIF−OUT.W3

AIF−OUT.
D1

Speed control

1003
1013
1113

MCTRL−NACT
Actual speed value
"100%= "16383

MCTRL−MSET2
Torque display
"100%= "16383

MCTRL−NSET2
Speed controller input
"100%= "16383

Not used

Torque control

4003
4013
4113

MCTRL−MSET2
Torque display
"100%= "16383

MCTRL−NACT
Actual speed in %
"100%= "16383

MCTRL−NSET2
Speed controller input
"100%= "16383

Not used

LF master

5003
5013
5113

MCTRL−NACT
Actual speed value
"100%= "16383

MCTRL−MSET2
Torque display
"100%= "16383

MCTRL−NSET2
Speed controller input
"100%= "16383

Not used

LF slave rail

6003
6013
6113

MCTRL−NACT
Actual speed value
"100%= "16383

MCTRL−PHI−ACT
Angle actual value

MCTRL−MSET2
Torque setpoint in %
"100%= "16383

Not used

LF slave cascade

7003
7013
7113

MCTRL−NACT
Actual speed value
"100%= "16383

MCTRL−PHI−ACT
Angle actual value

MCTRL−MSET2
Torque setpoint in %
"100%= "16383

Not used

Not equal to
xxx3
(except for own
configurations)

MCTRL−NACT
Actual speed value
"100%= "16383

MCTRL−MSET2
Torque display
"100%= "16383

MCTRL−PHI−ACT
Angle actual value

Not used

In the controller, the signals AIF−OUT.W1 ... W3 can be assigned to other signals. For this,
the system block configuration is used. The AIF−OUT system block defines the output data
of the controller as data interface to the communication module.

Detailed information on system block configuration, 93XX signal configurations (main
configurations 1000, 4000, 5000 etc.) and the AIF−OUT system block can be found in the
documentation of the 93XX controller.
