Parameter data transfer
PROFIdrive parameter data channel
PROFIdrive DP−V1
8
l
108 EDSMF2133IB EN 5.0
8.3.1.11 Programming of write requests
Procedure
1. Define the user data range of the controller (define the location of the user data in
the host system).
Observe manufacturer−specific data.
2. Enter the code of the desired parameter into the "code" field (output data).
3. Enter parameter value into the "Data/Error" field.
4. Job identification / service = write request
5. Check whether index and subindex correspond with the job and whether the job
identification is
Ø 0:
– If the criteria are fulfilled, the desired master data from the field "Parameter
value" are accepted by the controller.
– If these criteria are not fulfilled, the response identifier is negative (high nibble of
byte 1 = 7
hex
). In this case, the error information can be read out from the entry in
the low word.
Example:
The controller acceleration time (C0012) is to be set to 20 s.
ƒ Job identification (high nibble in byte 1)
Transmit simple parameter value: "1"
ƒ Code: (low nibble in byte 1 and byte 2)
C0012: 12 = 0C
hex
ƒ Lenze subcode (byte 3):
Subindex = 0, as there is not subindex under code C0012.
ƒ Bytes 5 ...8: Data
Data 1 ... 4 = 20 s x 10000 = 200000 = 00030D40
hex
Result:
ƒ Request telegram from master to drive:
Byte 1* Byte 1* +2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
AK Code Subcode Reserved Parameter value
3
hex
00C
hex
00
hex
00
hex
00
hex
03
hex
0D
hex 40hex
0011 bin 000000001100 bin 00000000 bin 00000000 bin 00000000 bin 00000011 bin 00001101 bin 01000000 bin
Wait for response identification with code = 00C and subcode 0
ƒ Response telegram from drive to master (for faultless execution):
Byte 1* Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
AK Code Subcode Reserved Parameter value
2
hex
00C
hex
00
hex
00
hex
00
hex
00
hex
00
hex
00
hex
0010
bin
000000001100
bin
00000000
bin
00000000
bin
00000000
bin
00000000
bin
00000000
bin
00000000
bin
