90 Instructions for Use V 3.0 RevE – 04/2013
8. Malfunctions and Troubleshooting
8.1 Error codes (continued)
Display Cause Troubleshooting
Error 313
TS-Z BLOCKED
The transfer arm of the
TS5025/5015 Transfer Sta-
tion is blocked in its up/
down movement (Z-axis).
Remove the cause of the blockage (specimen slide holder) and
inspect the transfer arm of the TS5025/TS5015. Remove empty
specimen slide holders from the discharge chute of the transfer
station. Switch the instrument off and on. Proceed further as de-
scribed in Chapter 5.3 . Place any removed specimen slide holders
into the coverslipper and have them coverslipped (thus outside of
the workstation operation).
Error 314
TS-AX BLOCKED
The gripper of the TS5015
Transfer Station is blocked
in its left/right movement
(X-axis).
Remove the cause of the blockage (specimen slide holder) and
inspect the gripper of the TS5015. Remove empty specimen
slide holders from the discharge chute of the transfer station.
Switch the instrument off and on. Proceed further as described
in Chapter 5.3 . Place any removed specimen slide holders into
the coverslipper and have them coverslipped (thus outside of the
workstation operation).
Error 315
TS-AY BLOCKED
The carriage of the TS5015
Transfer Station is blocked
in its forward/backward
movement (Y-axis).
Remove the cause of the blockage (specimen slide holder) and
inspect the carriage of the TS5015. Remove empty specimen
slide holders from the discharge chute of the transfer station.
Switch the instrument off and on. Proceed further as described
in Chapter 5.3 . Place any removed specimen slide holders into
the coverslipper and have them coverslipped (thus outside of the
workstation operation).
Error 316
TS-AZ BLOCKED
The gripper of the T5015
Transfer Station is blocked
in its up/down movement
(Z-axis).
Remove the cause of the blockage (specimen slide holder) and
inspect the gripper of the TS5015. Remove empty specimen
slide holders from the discharge chute of the transfer station.
Switch the instrument off and on. Proceed further as described
in Chapter 5.3 . Place any removed specimen slide holders into
the coverslipper and have them coverslipped (thus outside of the
workstation operation).
Error 319
CS SENSOR DEF.
The cover slip sensor is
stuck or defective.
Clean the Pick & Place module and the cover slip sensor using
a lint-free cloth soaked in compatible solvent as described in
Chapter 7.5.10 .
Error 322
CONFIG FAULT
The reference values of the
instrument are faulty.
Contact Leica Service.
