19 Leica CV5030 – Robotic Coverslipper
Removing the accessories ( Fig. B )
• Remove the two screws ( Fig. A , 4) in the side
panel (left and right) and take out the transport
anchor (5).
• The box with accessories (6) can now be
removed from the shipping package.
Fig. B
5
6
7
4. Instrument Setup
4.2 Unpacking the CV5030 (continued)
Removing the instrument
• Unscrew the 8 screws ( Fig. A , 3) on the bottom
of the wooden box on the exterior. Carefully
remove the wooden box from the baseplate.
• Unscrew 2 x 4 screws (front and rear on the
instrument, (8) in Fig. C), loosen and remove the
retaining clips (9) from the baseplate.
• Remove the dust cover from the instrument.
For setting up the instrument,
refer to
Chapter 4.2.1 - Setting up the CV5030.
Fig. C
8
9
9
