Graphics printing definition
Code rotate, Y, hexp, vexp, 000, row, column, graphic
Setting rotate Sets graphic data rotation direction to 1 (fixed)
Y Y fixed
hexp Sets expansion rate in horizontal direction 1 - 9, A – O
(A - O corresponding to 10 - 24)
vexp Sets expansion rate in vertical direction 1 - 9, A - O
(A - O corresponding to 10 - 24)
000 000 fixed
row Row address 0000 - 9999
column Column address 0000 - 0398
graphic Specifies graphic file name to be printed
Function Picks out file name from the memory module and prints.
Caution Graphic file to be printed with this command must be stored in the
memory module.
Example Input data below represents that file name "IMAGE" in the memory
module is printed.
Input data [02] n Sets units to inch
[02] L Starts label format mode
1Y1100000500050IMAGE Sets graphic file name "IMAGE"
E Ends label format mode and prints
