General Information and Specifications
2-14
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
2.4
SPECIFICATIONS
2.4.1
Travel Speeds
2.4.2
Hydraulic Cylinder Performance
Note: Machine with no attachment or load, engine at full throttle, hydraulic oil above 54° C (130° F) minimum, engine
at operating temperature.
2.4.3
Platform Hydraulic Performance Specifications
First Gear
7 kph (4 mph)
Second Gear
12 kph (7 mph)
Third Gear
21 kph (13 mph)
Fourth Gear
32 kph (20 mph)
Fifth Gear (if equipped)
Up to 40 kph (25 mph)
Six Gear (if equipped)
Up to 40 kph (25 mph)
FUNCTION
APPROXIMATE TIMES (seconds)
3706PS
3707PS
33.7
37.6
37.7
4014PS
4017PS
Boom Extend (Boom Level)
4-7
5-8
3-7
4-7
5-8
10-13
22-26
Boom Retract (Boom Level)
4-6
5-7
3-7
4-6
5-7
10-15
15-25
Boom Lift
5-7
6-10
6-10
5-7
6-10
14-18
15-20
Boom Lower
3-6
5-9
5-8
3-6
5-9
8-13
12-15
Quick Coupler Raise
2-4
2-5
2-4
2-4
2-5
2-5
2-5
Quick Coupler Lower
2-4
2-4
2-4
2-4
2-4
2-5
3-6
Level - Full Right to Left
N/A
N/A
N/A
N/A
N/A
7-15
7-15
Level - Full Left to Right
N/A
N/A
N/A
N/A
N/A
7-12
7-15
Outrigger - Both Down
N/A
N/A
N/A
N/A
N/A
5-8
6-10
Outrigger - Both Up
N/A
N/A
N/A
N/A
N/A
4-9
5-9
Outrigger - Single Down
N/A
N/A
N/A
N/A
N/A
3-7
3-6
Outrigger - Single Up
N/A
N/A
N/A
N/A
N/A
3-7
3-6
FUNCTION
APPROXIMATE TIMES (seconds)
4014PS
4017PS
Platform Lift
31-60
39-60
Platform Lower
31-60
39-60
Platform Extend
19-35
27-43
Platform Retract
19-49
27-60
Platform Rotate 180°
14-40
14-40
