Electrical System
9-6
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Temperature:
Celsius
Celsius
Fahrenheit
Access Levels
1,2,3
Selects units for temperature display; default to
CELSIUS when Machine Setup’s MARKET is CE or
AUSTRALIA; default to FAHRENHEIT when MARKET is
ANSI
Oil Pressure:
Bar
BAR
PSI
Access Levels
1,2,3
Select units for oil pressure display; default to BAR when
Machine Setup’s MARKET is CE or AUSTRALIA; default
to PSI when MARKET is ANSI
Cabin Joystick:
Telescope: X-
AXIS
X-AXIS
ROLLER
Access Levels
1,2,3
Selects the cabin joystick resource that will be used to
control telescope; fork tilt is controlled by the opposite
Steer Mode:
Automatic
Automatic
Manual
Access Levels
1,2,3
Selects steering mode preference
Revise Engine
Hours?
Set Engine On
Hours: 0H
Access Level
1; Mechanical
Engine
Used to update engine on data log for service (rebuild or
replacement); mechanical engine only
LSI-CAN
SYSTEM
CHECK:
Perform LSI-
CAN System
Check? No
Access Levels
1,2; Machine
Setup’s LOAD
MONITORING
is LSI-CAN or
LSI-CAN +
LMI;
CALIBRATION
LSI-CAN
SYSTEM
CHECK
completed
The technician will press the UP / DOWN arrow keys to
select YES. When set to YES and ENTER button is
pressed, the control system will provide the following
directions
Remove
Weights And
Attachments.
The following directions will be displayed and when the
operator presses the ENTER button, the control system
will advance to the next menu screen
Fully Deploy
Stabilizers
Display when Machine Setup’s MODEL is 4014PS or
4017PS; the following directions will be displayed and
when the operator presses the ENTER button, the
control system will advance to the next menu screen
Telescope In
And Fully Lift
Up.
The following directions will be displayed and when the
operator presses the ENTER button, the control system
will advance to the next menu screen
**** Stop ****
Wait 1 Minute
The following directions will be displayed and when the
operator presses the ENTER button, the control system
will advance to the next menu screen
Press Enter To
Start Test: Pass
The technician will press the ENTER button to start the
control system comparative check of the LSI System
load sensor raw counts; PASS (within +/- 20 counts) or
FAIL will be indicated; the ESC button will used to exit
Review LSI
Suspended Log?
LSI Suspend
Log
NN: XXH YYM -
On
Access Level 1
Displays UGM operating hours and minutes when the
LSI-CAN suspended vehicle operation; ON during
passive mode and OFF otherwise (last ten events)
