k. Load Moment (85X)
LSS CELL #2 ERROR
822
Continuously
Platform assumed to be
overloaded
Machine Setup’s PLATFORM
OPTION is ENABLED; Load
Sensing System configured;
platform attached; key switch
platform;
LSS Module reports CELL 2
ERROR
Power cycled
LSS CELL #3 ERROR
823
Continuously
Platform assumed to be
overloaded
Machine Setup’s PLATFORM
OPTION is ENABLED; Load
Sensing System configured;
platform attached; key switch
platform;
LSS Module reports CELL 3
ERROR
Power cycled
LSS CELL #4 ERROR
824
Continuously
Platform assumed to be
overloaded
Machine Setup’s PLATFORM
OPTION is ENABLED; Load
Sensing System configured;
platform attached; key switch
platform;
LSS Module reports CELL 4
ERROR
Power cycled
LSS HAS NOT BEEN
CALIBRATED
825
Continuously
Platform assumed to be
overloaded
Machine Setup’s PLATFORM
OPTION is ENABLED; Load
Sensing System configured;
platform attached; key switch
platform; load sensing system has
not been calibrated
Successful
LSS
calibration
has been
performed
PLATFORM
FUNCTIONS CUTOUT
– PLATFORM
OVERLOADED
829
Continuously
Platform assumed to be
overloaded
Machine Setup’s LOAD SENSING
is PLATFORM CUTOUT; Key
switch Platform; Load Sensing
System detects an overload
(>110% or <50% rated load);
Load Sensing
System does
not detected
an overload
LOAD MOMENT
85XXX
-
-
-
-
LSI NOT
CALIBRATED
8514
5000mS
–
Load Monitoring configured;
LSI System reports Fault #6 –
System not calibrated
LSI System
does not
report Fault
#6
LSI DETECTED BUT
NOT CONFIGURED
8515
Continuously
Hydraulic functions are
prevented
Load Monitoring is not configured;
LSI System messages detected
Load
Monitoring is
configured
LSI LOAD CELL A –
OUT OF RANGE
8516
Continuously
Load Moment Cutout assumed to
be 100%
Load Monitoring configured;
LSI System reports Fault #4 –
Load Cell A – Out of Range
Power cycled
LSI LOAD CELL B –
OUT OF RANGE
8517
Continuously
Load Moment Cutout assumed to
be 100%
Load Monitoring configured;
LSI System reports Fault #5 –
Load Cell B – Out of Range
Power cycled
