Page 166

Electrical System
9-8
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
9.5.3
Calibration
Bucket
Telescope
Allows the owner to adjust the Max Bucket Tele In and Max
Bucket Tele Out function speeds
1300 mA
Bucket Tilt
Allows the owner to adjust the Max Bucket Tilt Up and Max
Bucket Tilt Down function speeds
1400 mA (up)
1600 mA (down)
Auxiliary
Function
Allows the owner to adjust the Accel, Decel, and Max Function
Coil A and Max Function Coil B function speeds
1500 mA
Function
Description
Default Value
Menu
SubMenu
Visible
Comment
Calibrations:
Tilt Sensor
Calibrate Tilt
Sensor?
Access Levels
1,2;
Machine Setup’s
PLATFORM
OPTION is
ENABLED
Use by technicians to calibrate the tilt sensor (integral
to UGM); press ENTER to confirm; ESC to exit
Tilt Calibration
Set Stabilizers
Displayed when Machine Setup’s STABILIZERS is
EQUIPPED and at least one stabilizer is not deployed;
press ENTER or ESC to exit
Tilt Sensor
Calibrating...
Displayed while control system averages readings
Calibration
Complete
Calibration offset was within +/- 8.0 degrees; press
ENTER or ESC to exit
Calibration Failed
Calibration offset was outside +/- 8.0 degrees; press
ENTER or ESC to exit
