Transmission
6-2
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
6.1
TRANSMISSION ASSEMBLY
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the transmission.
The following illustration identifies the components that
are referred to throughout this section.
MZ6860
TRANSMISSION
OIL DRAIN PLUG
REAR DRIVE
SHAFT YOKE
SHIFT SOLENOIDS
FRONT DRIVE
SHAFT YOKE
SHIFT SOLENOIDS
SPEED SENSOR
TRASFER CASE
OIL DRAIN PLUG
TRANSMISSION OIL
FILTER
TRANSMISSION OIL
DIPSTICK
TRANSMISSION OIL
FILL TUBE AND
BREATHER
TRASFER CASE
FILL & LEVEL
CHECK PLUG
TRANSFER CASE
BREATHER
