Electrical System
504
523915
4
7-2-0
HCI dosing valve (DV1); short circuit to ground
505
523915
11
7-2-0
HCI dosing valve (DV1); short circuit high side powerstage
506
523916
2
7-1-9
Sensor HCI dosing valve (DV1) downstream pressure; plausibility
error
508
523916
0
7-1-9
Physical range check high for HCI dosing valve
(DV1) downstream pressure; shut off regeneration
511
523916
1
7-1-9
Physical range check low for HCI dosing valve
(DV1) downstream pressure; shut off regeneration
514
523916
3
7-1-9
Sensor error HCI dosing valve (DV1) downstream pressure; signal
range check high
515
523916
4
7-1-9
Sensor error HCI dosing valve (DV1) downstream pressure; signal
range check low
516
523917
2
7-1-8
Sensor DV1 & DV2 upstream pressure; plausibility error
518
523917
0
7-1-8
Physical range check high for DV1 & DV2 upstream pressure; shut
off regeneration
521
523917
1
7-1-8
Physical range check low for DV1 & DV2 upstream pressure; shut
off regeneration
524
523917
3
7-1-8
Sensor error DV1 & DV2 upstream pressure;
signal range check high
525
523917
4
7-1-8
Sensor error DV1 & DV2 upstream pressure;
signal range check low
526
523918
2
7-1-7
Sensor DV1 & DV2 upstream temperature; plausibility error
528
523918
0
7-1-7
Physical range check high for DV1 & DV2 upstream temperature;
shut off regeneration
531
523918
1
7-1-7
Physical range check low for DV1 & DV2 upstream temperature;
shut off regeneration
534
523918
3
7-1-7
Sensor error DV1 & DV2 upstream temperature;
signal range check high
535
523918
4
7-1-7
Sensor error DV1 & DV2 upstream temperature;
signal range check low
543
676
11
2-6-3
Cold start aid relay error.
544
676
11
2-6-3
Cold start aid relay open load
545
729
5
2-6-3
Cold start aid relay open load
559
523895
13
7-0-6
Check of missing injector adjustment value programming (IMA)
injector 1 (in firing order)
