Page 237

9-79
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
9.18.3
Engine Fault Codes
FUNCTIONS
LOCKED OUT –
TCM
SOFTWARE
VERSION
IMPROPER
99163
Continuously
·Hydraulic functions are prevented
·Engine Start is prevented
·
·UGM J4-12 ECM / Fuel Relay is
energized to shutdown engine
TCM transmitted a Major Software
version that is not compatible (P4.x
allowed)
Power cycled
KWP
SPN
FMI
Blinkcode
Message
1
132
11
2-2-6
Air flow sensor load correction factor exceeding the maximum drift
limit; plausibility error
2
132
11
2-2-6
Air flow sensor load correction factor exceeding drift limit;
plausibility error
3
132
11
2-2-6
Air flow sensor low idle correction factor exceeding the maximum
drift limit
4
132
11
2-2-6
Air flow sensor load correction factor exceeding the maximum drift
limit
9
172
2
2-2-6
Sensor ambient air temperature; plausibility error
34
523006
3
2-4-2
Controller mode switch; short circuit to battery
35
523006
4
2-4-2
Controller mode switch; short circuit to ground
45
168
3
3-1-8
Sensor error battery voltage; signal range check high
46
168
4
3-1-8
Sensor error battery voltage; signal range check low
47
168
2
3-1-8
High battery voltage; warning threshold exceeded
48
168
2
3-1-8
Low battery voltage; warning threshold exceeded
49
597
2
3-2-1
Break lever main switch and break lever redundancy switch status
not plausible
55
523910
14
6-9-5
Air pump doesn't achieve air mass flow set point
56
524013
7
8-5-6
Burner flame unintentional deleted
57
524020
14
8-6-3
Engine power reduction due to low lambda
58
523911
0
7-2-3
Burner dosing valve (DV2); over current at the end of the injection
phase
59
523911
12
7-2-3
Burner dosing valve (DV2); powerstage over temperature
60
523911
3
7-2-3
Burner dosing valve (DV2); short circuit to battery
61
523911
3
7-2-3
Burner dosing valve (DV2); short circuit to battery on high side
62
523911
4
7-2-3
Burner dosing valve (DV2); short circuit to ground
63
523911
11
7-2-3
Burner dosing valve (DV2); short circuit high side powerstage
