Page 209

9-51
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
9.18.2
Machine Fault Codes
Message
Fault
Code
Indicators
Other Actions Taken
Trigger for Fault
Latch Until
HELP COMMENT
00XXX
EVERYTHING OK
001
The system detects no problems
exist.
POWER UP
21XXX
POWER CYCLE
211
-
-
Power was cycled ON.
-
FUNCTION
ENABLE INPUTS –
INVALID SIGNAL
STATES
214
Continuously
PLT J2-19 Function Enable Relay
shall be de-energized
Platform controls shall be
prevented
Machine Setup’s PLATFORM
OPTION is ENABLED; Platform
Mode; Key switch Platform; PLT J2-
19 Function Enable Relay is
energized; PLT J7-8 & UGM J7-15
Function Enable Switch digital
inputs are not complementary for
1000mS
Machine Setup’s PLATFORM
OPTION is ENABLED; Platform
Mode; Key switch Platform;
power-up; PLT J7-8 Function
Enable Switch digital input is
energized
Power cycled
JOYSTICK AXES
NOT IN NEUTRAL
POSITION AT
POWER UP
215
5000mS
The cabin joystick X & Y axis input
shall be ignored
The cabin joystick’s X or Y axis is
not neutral at power-up
The cabin
joystick’s X
and Y axis
return to
neutral
JOYSTICK S1
BUTTON ACTIVE
AT POWER UP
217
5000mS
The cabin joystick S1 push button
(downshift) is prevented
The cabin joystick’s S1 push button
(downshift) is pressed at power-up
The push
button is
released
JOYSTICK S2
BUTTON ACTIVE
AT POWER UP
218
5000mS
The cabin joystick S2 push button
(upshift) is prevented
The cabin joystick’s S2 push button
(upshift) is pressed at power-up
The push
button is
released
ENGINE START
PREVENTED –
PLATFORM
START SWITCH
HIGH AT POWER
UP
2111
5000mS
Platform Engine Start is prevented
Machine Setup’s PLATFORM
OPTION is ENABLED; Platform
Mode; PLT J1-14 Engine Start
Switch is closed at power-up
The switch is
open
momentarily
PLATFORM
ROTATE LEFT
PREVENTED –
INPUT HIGH AT
POWER UP
2112
5000mS
Platform Rotate Left & Right are
prevented
Machine Setup’s PLATFORM
OPTION is ENABLED; Platform
Mode; PLT J1-8 Platform Rotate
Left Switch is closed at power-up
Power cycled
PLATFORM
ROTATE RIGHT
PREVENTED –
INPUT HIGH AT
POWER UP
2113
5000mS
Platform Rotate Left & Right are
prevented
Machine Setup’s PLATFORM
OPTION is ENABLED; Platform
Mode; PLT J1-7 Platform Rotate
Right Switch is closed at power-up
Power cycled
