9-9
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
Calibrations:
Boom Angle
Calibrate Boom
Angle Sensor?
Access Levels
1,2;
Platform Not
Attached
Used by technicians to calibrate the boom angle
sensor; press ENTER to confirm; ESC to exit
Press Enter At
Lowest Position.
Technician must lower boom to mechanical stop, press
ENTER to confirm
Boom Angle:
Calibrating...
Displayed while control system averages readings
Lift Up. Press
Enter At Top.
Technician must raise boom to mechanical stop, press
ENTER to confirm.
Boom Angle:
Calibrating...
Displayed while control system averages readings
Calibration:
Complete
Calibration was successful; press ESC key to exit
Calibration:
Remove Platform
The platform was attached when the calibration was
initiated; press ESC key to exit
Calibration:
Failed
The minimum or maximum boom angle sensor counts
were improper for this vehicle; press ESC key to exit;
press LEFT or RIGHT for the BOOM ANGLE RAW
COUNTS display
Calibration:
Sensor Fault
DTC 2344, 2345, 2346, 2353, or 6621 was active and
calibration could not succeed; press ESC key to exit;
press LEFT or RIGHT for the BOOM ANGLE RAW
COUNTS display
Boom Angle Raw:
Counts: xxxx
Access Levels
1,2;
Machine Setup’s
MODEL is
4014PS or
4017PS; platform
is not attached
Displays the raw ADC counts for the CANbus boom
angle sensor after a SENSOR FAULT or FAILED event
Boom Angle Raw:
Counts: xxxx
Access Levels
1,2;
Machine Setup’s
MODEL is
3706PS or
3707PS
Displays the raw ADC counts for the boom angle
sensor from UGM J7-4 after a SENSOR FAULT or
FAILED event
