Page 221

9-63
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
AUXILIARY
FUNCTION-A/B
VALVES – SHORT
TO BATTERY
33197
Continuously
Auxiliary Function-A is prevented
Auxiliary Function-B is prevented
UGM J3-14 Aux Return is disabled
Continuous Auxiliary Hydraulics is
prevented
Hydraulic Quick Connect is
prevented
Auxiliary Release is prevented
Short to battery is detected on
UGM J2-9 or UGM J2-20
Power cycled
AUXILIARY
FUNCTION-A
VALVE – SHORT
TO GROUND
33198
Continuously
Auxiliary Function-A is prevented
Auxiliary Function-B is prevented
UGM J3-14 Aux Return is disabled
Continuous Auxiliary Hydraulics is
prevented
Hydraulic Quick Connect is
prevented
Auxiliary Release is prevented
Short to ground is detected on
UGM J2-9
Power cycled
AUXILIARY
FUNCTION-B
VALVE – OPEN
CIRCUIT
33199
5000mS
Auxiliary Function-B is prevented
Continuous Auxiliary Hydraulics is
prevented
Hydraulic Quick Connect is
prevented
Auxiliary Release is prevented
Open-circuit is detected on UGM
J2-20
Power cycled
AUXILIARY
FUNCTION-B
VALVE – SHORT
TO GROUND
33200
Continuously
Auxiliary Function-A is prevented
Auxiliary Function-B is prevented
UGM J3-14 Aux Return is disabled
Continuous Auxiliary Hydraulics is
prevented
Hydraulic Quick Connect is
prevented
Auxiliary Release is prevented
Short to ground is detected on
UGM J2-20
Power cycled
STABILIZER/
FRAME LEVEL
SPEED VALVE –
OPEN CIRCUIT
33201
5000mS
Stabilizers are prevented
Frame Level is prevented
Cabin Mode; Machine Setup’s
MODEL is 4014 or 4017; open-
circuit is detected on UGM J1-3
Power cycled
STABILIZER/
FRAME LEVEL
SPEED VALVE –
SHORT TO
BATTERY
33202
Continuously
Stabilizers are prevented
Frame Level is prevented
UGM J3-5 Stabilizer / Frame Level
Speed Return is disabled
Cabin Mode; Machine Setup’s
MODEL is 4014 or 4017; short to
battery is detected on UGM J1-3
Power cycled
STABILIZER/
FRAME LEVEL
SPEED VALVE –
SHORT TO
GROUND
33203
Continuously
Stabilizers are prevented
Frame Level is prevented
UGM J3-5 Stabilizer / Frame Level
Speed Return is disabled
Cabin Mode; Machine Setup’s
MODEL is 4014 or 4017; short to
ground is detected on UGM J1-3
Power cycled
HYDRAULIC
QUICK CONNECT
SELECT – OPEN
CIRCUIT
33204
5000mS
Hydraulic Quick Connect is
prevented
Machine Setup’s HYDRAULIC
QUICK CONNECT is YES; open-
circuit is detected on UGM J1-23
Power cycled
