Electrical System
9-80 3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
64 523912 2 7-2-2
Burner dosing valve (DV2) downstream pressure sensor;
plausibility error
66 523912 0 7-2-2
Physical range check high for burner dosing valve
(DV2) downstream pressure; shut off regeneration
69 523912 1 7-2-2
Physical range check low for burner dosing valve (DV2)
downstream pressure; shut off regeneration. When burner injector
is actuated, the measured pressure does not rise above ca.
1250mbar abs (expected: ca. 2400mbar).
72 523912 3 7-2-2
Sensor error burner dosing valve (DV2) downstream pressure
sensor; signal range check high
73 523912 4 7-2-2
Sensor error burner dosing valve (DV2) downstream pressure
sensor; signal range check low
74 523913 3 7-2-1
Sensor error glow plug control diagnostic line voltage; signal range
check high
75 523913 4 7-2-1
Sensor error glow plug control diagnostic line voltage; signal range
check low
76 523914 5 7-2-1 Glow plug control; open load
77 523914 12 7-2-1 Glow plug control; powerstage over temperature
78 523914 3 7-2-1 Glow plug control; short circuit to battery
79 523914 4 7-2-1 Glow plug control; short circuit to ground
84 639 14 2-7-1 CAN-Bus 0 "Bus Off-Status"
85 1231 14 2-7-1 CAN-Bus 1 "Bus Off-Status"
86 1235 14 2-7-1 CAN-Bus 2 "Bus Off-Status"
88 102 2 2-2-3 Charged air pressure above warning threshold
89 102 2 2-2-3 Charged air pressure above shut off threshold
96 110 3 2-2-5 Sensor error coolant temperature; signal range check high
97 110 4 2-2-5 Sensor error coolant temperature; signal range check low
98 110 0 2-3-2 High coolant temperature; warning threshold exceeded
99 110 0 2-3-2 High coolant temperature; shut off threshold exceeded
101 111 1 2-3-5 Coolant level too low
109 523929 0 7-2-4
Fuel Balance Control integrator injector 1 (in firing order);
maximum value exceeded
110 523930 0 7-2-4
Fuel Balance Control integrator injector 2 (in firing order);
maximum value exceeded
