Electrical System
9-56 3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
HYDRAULIC
FILTER
RESTRICTION
2332 5000mS –
Ten minutes after power-up, UGM
J2-24 Hydraulic Filter Restriction
Switch digital input is grounded for
3,000mS
UGM J2-24
Hydraulic
Filter
Restriction
Switch digital
input is not
grounded for
1,000mS
ALL WHEEL STEER
INPUT – INVALID
SIGNAL
2333 5000mS
All Wheel Steer Mode Switch is
ignored
UGM J4-35 All Wheel Steer digital
input is energized at power up or for
7,000mS
Power cycled
CRAB STEER
INPUT – INVALID
SIGNAL
2334 5000mS Crab Steer Mode Switch is ignored
UGM J4-34 Crab Steer digital input
is energized at power up or for
7,000mS
Power cycled
JOYSTICK LOCK
INPUT – INVALID
SIGNAL
2335 5000mS Joystick Lock Switch is ignored
Machine Setup’s MARKET is CE or
AUSTRALIA; UGM J7-11 Joystick
Lock digital input is energized at
power up or for 7,000mS
Power cycled
LOAD MOMENT
SHUTOFF INPUT –
INVALID SIGNAL
2336 5000mS
Load Moment Shutoff Switch is
ignored
Machine Setup’s MARKET is CE or
AUSTRALIA; UGM J4-33 Load
Moment Shutoff digital input is
energized at power up or for 40
Seconds
Power cycled
BUCKET MODE
INPUT – INVALID
SIGNAL
2337 5000mS
Bucket Mode Switch is ignored
Fork Tilt Mode is engaged
UGM J4-19 Bucket Mode digital
input is energized at power up or for
7,000mS
Power cycled
2–WHEEL STEER
INPUT – INVALID
SIGNAL
2338 5000mS 2-Wheel Steer Switch is ignored
UGM J3-9 2-Wheel Steer digital
input is energized at power up or for
7,000mS
Power cycled
KEYPAD OK
BUTTON – INVALID
SIGNAL
2339 5000mS Keypad OK button is ignored
The keypad OK button is closed at
power up or for 7,000mS
Power cycled
KEYPAD CANCEL
BUTTON – INVALID
SIGNAL
2340 5000mS Keypad Cancel button is ignored
The keypad Cancel button is closed
at power up or for 7,000mS
Power cycled
KEYPAD UP
BUTTON – INVALID
SIGNAL
2341 5000mS Keypad Up button is ignored
The keypad Up button is closed at
power up or for 7,000mS (except in
Analyzer Mode)
Power cycled
KEYPAD DOWN
BUTTON – INVALID
SIGNAL
2342 5000mS Keypad Down button is ignored
The keypad Down button is closed
at power up or for 7,000mS (except
in Analyzer Mode)
Power cycled
