Electrical System
9-10
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Calibrations:
LSS
Platform Type:
350-extendable
Access Levels
1,2;
Machine Setup’s
LOAD SENSING
is WARN ONLY
or PLATFORM
CUTOUT
Used by technicians to calibrate the platform load
sensing system; use LEFT, RIGHT, UP, DOWN to
select 350-EXTENDABLE or 450-FIXED; press
ENTER to continue or ESC to exit
Stabilizers
Not Deployed
Displayed when Machine Setup’s STABILIZERS is
EQUIPPED and at least one stabilizer is not deployed;
press ENTER or ESC to exit
Confirm Platform
Is Empty: No
Use LEFT, RIGHT, UP, DOWN to select YES; press
ENTER to continue or ESC to exit
Calibration
In Progress
Displayed while control system averages readings
Calibration
Complete
The 350-EXTENDABLE was 850-1300LBS empty; the
450-FIXED was 176-375LBS empty; calibration was
successful; press ESC to exit
Calibration
Failed
The platform was outside weight limits or the reading
could not be recorded in the LSS Module
Calibrations:
Stabilizers
Press Enter To
Use Stabilizers
Access Level 1;
Machine Setup’s
MODEL is
4014PS or
4017PS
Used by technicians during the manufacturing process
to move the stabilizers before the boom is fitted and
the boom angle sensor is calibrated; interlocks that
prevent stabilizer movement while the boom is
elevated are ignored; press ENTER to continue or
ESC to exit
*Warning*
Safeties Offline
Press ESC Button
When Test Done
Calibrations:
Boom Ride
Test
Confirm Boom
Ride Test: No
Access Level 1;
Machine Setup’s
BOOM RIDE is
YES
UP and DOWN select NO or YES; press ENTER while
YES to energize boom ride valves with the vehicle
stationary; interlocks that prevent boom ride while
stationary are ignored
Press Enter
When Test Done
Press ENTER to complete test
