9-65
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
AUXILIARY
FUNCTION
SELECT – SHORT
TO BATTERY
33217
Continuously
Auxiliary Function-A is prevented
Auxiliary Function-B is prevented
UGM J3-14 Aux Return is disabled
Continuous Auxiliary Hydraulics is
prevented
Hydraulic Quick Connect is
prevented
Auxiliary Release is prevented
Machine Setup’s AUXILIARY
FUNCTION SELECT is YES;
Cabin Mode is selected; short to
battery is detected on UGM J2-1
Power cycled
AUXILIARY
FUNCTION
SELECT – SHORT
TO GROUND
33218
Continuously
Auxiliary Function-A is prevented
Auxiliary Function-B is prevented
UGM J3-14 Aux Return is disabled
Continuous Auxiliary Hydraulics is
prevented
Hydraulic Quick Connect is
prevented
Auxiliary Release is prevented
Machine Setup’s AUXILIARY
FUNCTION SELECT is YES;
Cabin Mode is selected; short to
ground is detected on UGM J2-1
Power cycled
LEFT STABILIZER
DOWN VALVE –
OPEN CIRCUIT
33222
5000mS
Left & Right Stabilizer Down is
prevented
Machine Setup’s MODEL is 4014
or 4017; open circuit is detected on
UGM J2-21
Power cycled
LEFT STABILIZER
DOWN VALVE –
SHORT TO
BATTERY
33223
Continuously
Stabilizers are prevented
Frame Level is prevented
Machine Setup’s MODEL is 4014
or 4017; short to battery is
detected on UGM J2-21
Power cycled
LEFT STABILIZER
DOWN VALVE –
SHORT TO
GROUND
33224
5000mS
Left & Right Stabilizer Down is
prevented
Machine Setup’s MODEL is 4014
or 4017; short to ground is
detected on UGM J2-21
Power cycled
LEFT STABILIZER
UP VALVE – OPEN
CIRCUIT
33225
5000mS
Stabilizers are prevented
Machine Setup’s MODEL is 4014
or 4017; open circuit is detected on
UGM J2-10
Power cycled
LEFT STABILIZER
UP VALVE –
SHORT TO
BATTERY
33226
Continuously
Stabilizers are prevented
Frame Level is prevented
Machine Setup’s MODEL is 4014
or 4017; short to battery is
detected on UGM J2-10
Power cycled
LEFT STABILIZER
UP VALVE –
SHORT TO
GROUND
33227
5000mS
Stabilizers are prevented
Machine Setup’s MODEL is 4014
or 4017; short to ground is
detected on UGM J2-10
Power cycled
RIGHT
STABILIZER
DOWN VALVE –
OPEN CIRCUIT
33228
5000mS
Left & Right Stabilizer Down is
prevented
Machine Setup’s MODEL is 4014
or 4017; open circuit is detected on
UGM J2-15
Power cycled
RIGHT
STABILIZER
DOWN VALVE –
SHORT TO
BATTERY
33229
Continuously
Stabilizers are prevented
Frame Level is prevented
Machine Setup’s MODEL is 4014
or 4017; short to battery is
detected on UGM J2-15
Power cycled
RIGHT
STABILIZER
DOWN VALVE –
SHORT TO
GROUND
33230
5000mS
Left & Right Stabilizer Down is
prevented
Machine Setup’s MODEL is 4014
or 4017; short to ground is
detected on UGM J2-15
Power cycled
