9-95
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
1066
1180
11
5-5-6
Sensor exhaust gas temperature upstream turbine; plausibility
error
1067
1180
3
5-5-6
Sensor error exhaust gas temperature upstream turbine; signal
range check high
1068
1180
4
5-5-6
Sensor error exhaust gas temperature upstream turbine; signal
range check low
1069
4360
0
6-6-8
Physical range check high for urea catalyst upstream temperature
1070
4360
1
6-6-8
Physical range low for urea catalyst upstream temperature
1072
4360
3
6-6-8
Sensor error urea catalyst exhaust gas temperature upstream;
signal range check high
1073
4360
4
6-6-8
Sensor error urea catalyst exhaust gas temperature upstream;
signal range check low
1074
1761
14
6-7-0
Urea tank level; warning threshold exceeded
1077
3361
3
6-7-7
Urea dosing valve; short circuit to battery
1078
3361
3
6-7-7
Urea dosing valve high side; short circuit to battery
1079
3361
4
6-7-7
Urea dosing valve low side; short circuit to ground
1080
3361
4
6-7-7
Urea dosing valve high side; short circuit
1081
4345
5
6-7-4
SCR heater relay urea return line; open load
1082
523909
5
7-6-2
SCR main relay: cable break
1083
4343
5
6-7-3
SCR heater relay urea pressure line; open load
1084
4366
5
7-6-2
SCR main relay: shortcut to battery
1085
4366
5
7-6-2
SCR main relay: shortcut to ground
1086
4341
5
6-7-5
SCR-heater relay urea supply line; open load
1087
523719
5
6-7-2
SCR heater relay urea supply module; open load
1088
4366
5
6-7-1
Tank heating valve: open load
1089
4243
11
7-8-3
Urea pressure line heating procedure not successful; shut off
SCR-system
1090
4345
5
6-7-4
SCR-heater urea return line; open load
1092
4345
3
6-7-4
SCR-heater urea return line; short circuit to battery
1093
4345
4
6-7-4
SCR-heater urea return line; short circuit to ground
1094
4343
5
6-7-3
SCR-heater urea pressure line; open load
1096
4343
3
6-7-3
SCR-heater urea pressure line; short circuit to battery
1097
4343
4
6-7-3
SCR-heater urea pressure line; short circuit to ground
