9-93
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
969
624
5
5-1-3
SVS lamp; open load
970
624
12
5-1-3
SVS lamp; powerstage over temperature
971
624
3
5-1-3
SVS lamp; short circuit to battery
972
624
4
5-1-3
SVS lamp; short circuit to ground
973
523612
14
5-5-5
Software reset CPU SWReset_0
974
523612
14
5-5-5
Software reset CPU SWReset_1
975
523612
14
5-5-5
Software reset CPU SWReset_2
976
91
11
2-2-6
Plausibility error between APP1 and APP2 or APP1 and idle switch
980
523550
12
5-1-5
T50 start switch active for too long
981
172
3
2-2-6
Sensor error intake air; signal range check high
982
172
4
2-2-6
Sensor error intake air sensor; signal range check low
984
523921
11
7-1-4
Sensor burner temperature; plausibility error
986
523921
0
7-1-4
Physical range check high for burner temperature
989
523921
1
7-1-4
Physical range check low for burner temperature
994
105
3
1-2-8
Sensor error charged air temperature; signal range check high
995
105
4
1-2-8
Sensor error charged air temperature; signal range check low
996
105
0
2-3-3
High charged air cooler temperature; warning threshold exceeded
997
105
0
2-3-3
High charged air cooler temperature; shut off threshold exceeded
1007
412
3
6-8-2
Sensor error EGR cooler downstream temperature; signal range
check high
1008
412
4
6-8-2
Sensor error EGR cooler downstream temperature; signal range
check low
1011
523960
0
7-7-1
Physical range check high for EGR cooler downstream
temperature
1012
523960
1
7-7-1
Physical range check low for EGR cooler downstream temperature
1014
51
6
5-9-4
Actuator error EGR-Valve (2.9;3.6) or Throttle- Valve (6.1,7.8);
signal range check high
1015
51
5
5-9-4
Actuator error EGR-Valve (2.9;3.6) or Throttle- Valve (6.1,7.8);
signal range check low
1016
51
7
5-9-4
Actuator position for EGR-Valve (2.9,3.6) or
Throttle-Valve (6.1,7.8) not plausible
1017
51
5
5-9-4
Actuator EGR-Valve (2.9;3.6) or Throttle-Valve
(6.1,7.8); open load
