9-99
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
Electrical System
1249
523910
7
6-9-5
Air pump; CAN communication interrupted no purge function
available
1250
523910
12
6-9-5
Air Pump; internal error
1251
523910
0
6-9-5
Air Pump; powerstage over temperature
1252
523910
0
6-9-5
Air Pump; operating voltage error
1253
523911
7
8-5-0
Burner dosing valve (DV2); blocked closed
1254
524014
1
8-5-8
Air pressure glow plug flush line; below limit
1255
524013
7
8-5-7
Burner operation is interrupted too often
1256
523915
7
8-5-2
HCI dosing valve (DV1); blocked closed
1257
523915
7
8-5-3
HCI dosing valve (DV1); blocked open
1258
524016
11
8-5-9
HFM sensor; electrical fault
1259
524016
2
8-5-9
Amount of air is not plausible to pump speed
1260
524016
2
8-5-9
Calculated amount of air is not plausible to HFM reading
1261
523910
6
6-9-5
Air Pump; over current
1262
523922
7
8-5-4
Shut Off Valve; blocked closed
1263
524021
11
8-6-4
Fuel line pipe leak behind Shut Off Valve
1264
523922
7
8-5-5
Shut Off Valve; blocked open
1265
524017
12
8-6-0
Spark plug control unit (SPCU); electrical fault
1266
524017
12
8-6-1
Spark plug control unit (SPCU); internal error
1267
523989
0
7-2-4
Fuel Balance Control integrator injector 7 (in firing order);
maximum value exceeded
1268
523990
0
7-2-4
Fuel Balance Control integrator injector 8 (in firing order);
maximum value exceeded
1269
523989
1
7-2-4
Fuel Balance Control integrator injector 7 (in firing order); minimum
value exceeded
1270
523990
1
7-2-4
Fuel Balance Control integrator injector 8 (in firing order); minimum
value exceeded
1279
523992
9
Time out Error of CAN-Receive-Frame DM19Vol1; NOX sensor
upstream
1283
523993
9
Time out Error of CAN-Receive-Frame DM19Vol2; NOX sensor
downstream
1285
524038
9
Time out error of CAN-Receive-Frame ComMS_Sys1TO (error
memory Slave); Master- Slave internal CAN message
1286
524039
9
Time out error of CAN-Receive-Frame ComMS_Sys2TO (error
memory Slave); Master- Slave internal CAN message
