Electrical System
9-66
3706PS, 3707PS, 4014PS, 4017PS, 33.7, 37.6, 37.7
RIGHT
STABILIZER UP
VALVE – OPEN
CIRCUIT
33231
5000mS
Stabilizers are prevented
Machine Setup’s MODEL is 4014
or 4017; open circuit is detected on
UGM J2-3
Power cycled
RIGHT
STABILIZER UP
VALVE – SHORT
TO BATTERY
33232
Continuously
Stabilizers are prevented
Frame Level is prevented
Machine Setup’s MODEL is 4014
or 4017; short to battery is
detected on UGM J2-3
Power cycled
RIGHT
STABILIZER UP
VALVE – SHORT
TO GROUND
33233
5000mS
Stabilizers are prevented
Machine Setup’s MODEL is 4014
or 4017; short to ground is
detected on UGM J2-3
Power cycled
FRAME LEVEL
LEFT VALVE –
OPEN CIRCUIT
33234
5000mS
Frame Level Left is prevented
Machine Setup’s MODEL is 4014
or 4017; open circuit is detected on
UGM J2-7
Power cycled
FRAME LEVEL
LEFT VALVE –
SHORT TO
BATTERY
33235
Continuously
Stabilizers are prevented
Frame Level is prevented
Machine Setup’s MODEL is 4014
or 4017; short to battery is
detected on UGM J2-7
Power cycled
FRAME LEVEL
LEFT VALVE –
SHORT TO
GROUND
33236
5000mS
Frame Level Left is prevented
Machine Setup’s MODEL is 4014
or 4017; short to ground is
detected on UGM J2-7
Power cycled
FRAME LEVEL
RIGHT VALVE –
OPEN CIRCUIT
33237
5000mS
Frame Level Right is prevented
Machine Setup’s MODEL is 4014
or 4017; open circuit is detected on
UGM J2-5
Power cycled
FRAME LEVEL
RIGHT VALVE –
SHORT TO
BATTERY
33238
Continuously
Stabilizers are prevented
Frame Level is prevented
Machine Setup’s MODEL is 4014
or 4017; short to battery is
detected on UGM J2-5
Power cycled
FRAME LEVEL
RIGHT VALVE –
SHORT TO
GROUND
33239
5000mS
Frame Level Right is prevented
Machine Setup’s MODEL is 4014
or 4017; short to ground is
detected on UGM J2-5
Power cycled
CRAB STEER
VALVE – OPEN
CIRCUIT
33270
5000mS
Open-circuit is detected on UGM
J2-16
Power cycled
CRAB STEER
VALVE – SHORT
TO BATTERY
33271
5000mS
Short to battery is detected on
UGM J2-16
Power cycled
CRAB STEER
VALVE – SHORT
TO GROUND
33272
5000mS
Short to ground is detected on
UGM J2-16
Power cycled
ALL WHEEL
STEER VALVE –
OPEN CIRCUIT
33273
5000mS
Open-circuit is detected on UGM
J2-4
Power cycled
ALL WHEEL
STEER VALVE –
SHORT TO
BATTERY
33274
5000mS
Short to battery is detected on
UGM J2-4
Power cycled
