Compact T1 - Release 6.1 4-21
Configuration
Setup of DS0 Management Channel
Remote Site C Configuration
Test
After configuring all the Compact T1, verify connectivity to the NMS from each Unit.
> Ping 192.168.0.254
Response should be:
>192.168.0.254 is reachable
Command Description
disconnect a Disconnects all connections to slot a (controller)
set a:1:all type data Sets all DS0s on T1-1 to data signaling type
set a:2:all type data Sets all DS0s on T1-2 to data signaling type
disconnect 6 Disconnects the router in slot 6
set 6:1:all type data Sets all DS0s on slot 6 to data signaling type
connect a:1:11-14 a:2:1-4 Connect channels to cell site C
connect a:1:16-19 6:1:1-4 Connect channels to cell site D1
connect a:1:21-24 6:2:1-4 Connect channels to cell site D2
set ipds0 assign a:1:15 Assign channel to IPDS0 management channel
set ipds0 ip address
192.168.1.103 255.255.255.0
Configure IPDS0 ip address
set ipds0 up Enable IPDS0
set ipds0 navalarm off Suppress IPDS0 alarm
set snmp nms 1 192.168.0.254 Set up SNMP Trap address for the Compact T1
