3-10 Compact T1 - Release 6.1
Electrical Installation and Cabling
Interface Connectors
Pair Pin Location Function Color Code
11 36
11 Tip Channel 11
Ring Channel 11 Black/Blue
Blue/Black
12 37
12 Tip Channel 12
Ring Channel 12 Black/Orange
Orange/Black
13 38
13 Tip Channel 13
Ring Channel 13 Black/Green
Green/Black
14 39
14 Tip Channel 14
Ring Channel 14 Black/Brown
Brown/Black
15 40
15 Tip Channel 15
Ring Channel 15 Black/Slate
Slate/Black
16 41
16 Tip Channel 16
Ring Channel 16 Yellow/Blue
Blue/Yellow
17 42
17 Tip Channel 17
Ring Channel 17 Yellow/Orange
Orange/Yellow
18 43
18 Tip Channel 18
Ring Channel 18 Yellow/Green
Green/Yellow
19 44
19 Tip Channel 19
Ring Channel 19 Yellow/Brown
Brown/Yellow
20 45
20 Tip Channel 20
Ring Channel 20 Yellow/Slate
Slate/Yellow
21 46
21 Tip Channel 21
Ring Channel 21 Violet/Blue
Blue/Violet
22 47
22 Tip Channel 22
Ring Channel 22 Violet/Orange
Orange/Violet
23 48
23 Tip Channel 23
Ring Channel 23 Violet/Green
Green/Violet
24 49
24 Tip Channel 24
Ring Channel 24 Violet/Brown
Brown/Violet
25 50
25 Reserved Violet/Slate
Slate/Violet
