Compact T1 - Release 6.1 15-3
V.35/V.54 Cards
Features
Features
l Provides any n x 56/64 Kbps data rate up to 1.536 Mbps on each port
l Supports full non-blocking cross-connection of all timeslots to any T1 access line
l Enables up to 12 V.35 ports may be equipped in a single Compact T1
l
Allows a total of 24 V.35 ports to be equipped in two Compact T1, occupying
only two rack units of equipment space in a 19-inch rack
l Includes integration of T1 CSU/DSU functionality and remote management
capabilities
l Supports adaptation and transport over TDM facilities
l Integrates frame relay or private line V.35 services with voice and Internet access
over T1 lines
Additional V.54 Features
l V.54 Loop Test capability
Technical Specifications
Controller Software Required
T1 Controller
l Release 1.2.2 or higher is required for the V.35 card
l Release 3.0 or higher is required for the V.35/V.54 card
Service Interface
l
Two V.35 interfaces:
- DCE to DTE pinout
- Two sub-miniature DB-26 connectors
-
Adapters outlined below
