Compact T1 - Release 6.1

4-9

Configuration

Basic System Setup

Set Up the OCU-DP Card

The following is a basic setup for the OCU-DP card.

Command

Description

set {ocudp-addr} baud

{2400|4800|9600|19200|38400|

56000*|64000}

Set the OCU-DP Baud rate.
Where ocudp-addr = {slot:port} of the
OCU-DP card to apply settings to

set {ocudp-addr} up

Set the OCU-DP port 1 up

show {ocudp_card-addr}

Show the OCU-DP card settings.
Where ocudp_card-addr = {slot} of the
OCU-DP card

disconnect a

Disconnects all connections to slot a
(controller)

set {ds0-addr} type data

Sets a DS0 data signaling type

connect {ds0-addr}

{ocudp-addr}

Connects DS0 (in previous step) to OCU-DP
port (in previous step)

show connect

(ocudp_card-addr}

Displays connect information for OCU-DP
card
