Bulk cat5 siamese cables

Install one cable run instead of two
with these CAT5 cables.
Install one cable run instead of two
with these CAT5 cables.
Bulk CAT5 Siamese Cables
© 2007. All rights reserved. Black Box Corporation.
FREE 24-hour Tech Support: 724-746-5500
blackbox.com
7/6/2007
#23173
TECH SPECS
Conductor — 24 AWG solid bare copper per ASTM B-3
Number of Conductors — (8) total with (2) 2-pair cables
Insulation — PVC
Jacket — PVC gray
Calculated Cable Outside Diameter — 0.17" x 0.36" (4.3 x 9.1 mm)
Mutual Capacitance — 17 pF/ft. @ 1 kHz
Impedance — 100 ohms @ 1 to 100 MHz
Resistance — 28.6 ohms/1000 ft.
Weight — EVNSL17A-0500: 20 lb. (9.1 kg)
Item
Code
Bulk CAT5 Siamese Cable, Solid, 4-Pair (Total)
PVC
500-ft. (152.4-m)
EVNSL17A-0500
Custom Lengths
EVNSL17A
FEATURES
• Cables provide four pairs in two separate jackets
(two twisted pairs in each jacket) that are physically
joined together.
• Use each 2-pair bundle for a different application.
CAT5 Group Twist
The components are twisted into pairs to minimize
crosstalk. Two pairs are then cabled together inside each
of the two jackets. As a result, there are two independent
jackets containing two pairs each.
Jacket #1
Jacket #2
Pair Color
Pair
Color
1
White/Blue + Blue
1
White/Green + Green
2
White/Orange + Orange
2
White/Brown + Brown
INDIVIDUAL CONDUCTOR COLORS
