Rack mounting (optional feature), Rack mounting (optional feature) -5 – Black Box COMPACT T1 MT850A User Manual
Page 47
Compact T1 - Release 6.1
2-5
Physical
Installation
Rack Mounting (Optional Feature)
Rack Mounting (Optional Feature)
Rack mounting kits are available for both 19 and 23 inch racks.
To rack mount the Unit, follow the instructions below:
1. Attach bracket ears to rack mounting bracket using four #8-32 x 3/16" screws
on each side.
Bracket Ear
Left Side View
