Compact T1 - Release 6.1
11-5
Power Supply
Input Power
Interface Connectors
l
IEC-320, 15 A 3-prong AC power receptacle
l
Rear PCB connector: Compact T1 backplane
Physical
l
Dimensions: 3.5 in. (H) x 2 in. (W) x 12 in. (D)
8.9 cm (H) x 5.1 cm (W) x 30.5 cm (D)
l
Weight: 115 VAC - 1 lb. 6 oz. (0.62 kg)
24 VDC - 1 lb. 9 oz. (0.71 kg)
For information on Compact T1 Environment required, see Installation Environment,
on page 2-2.
Input Power
The following graphic displays the back of the chassis with a 115 VAC/-48 VDC
Power Supply installed.
