IP Scanner 4
362/350/282/250/222/200 4-17
IP
Scan
ne
r
Chapter 4
Scanner Settings dialog box
This dialog box appears so that scan settings can be registered on the ma-
chine.
1
2
3
4
5
6
7
11
13
14
12
8
9
10
15
No. Element Name Description
1 “Scanner Key Name”
box Type in the name of the scan button that will appear in the
machine’s touch panel. If the “Save folder as a key” check
box in the main window was selected, a folder with the
same name as the button is created on the computer.
2 “Scan Area” box Select the area to be scanned. If “Auto Detect” is selected,
the scanning area is automatically determined according to
the size of the document.
3 “Quality” box Select the scanning resolution.
4 “Contrast” slider Specify the density for scanning.
5 “Drop Out Color” check
box This item is not available with this machine.
6 “File Type” box Select “TIFF” or “PDF” for the format in which the file is
saved.
