12’ inch Length
6-Pin DIN Water Temperature & Level Sensor
Material No. 25751
120V
Part no 25404
cable Water detection
conductive 6 ft
Part no 8141-6320
Blower 600W htr 1hP
w/control 115v
Part no 90010
6 Button Panel
Blower or Pump
temperature and
Water level sensor
Part no 32016
sensor assy kit
(24in, 1/4in dia )
Sample 120V Bath Configuration
with a Primary Valve Control Box
to solenoids
Part no 90018
Primary valve Bath control
Common Configurations
Ir connection
by placing control
Boxes side by side
