Balboa Water Group Titan Bath Control - Manual (Page 13)

Manufactured under one or more of these patents. U.S. Patents: 5332944, 5361215, 5550753, 5559720, 5,883,459, 6253227, 6282370, 6590188, 6976052, 6965815, 7030343, 7,417,
834 b2, Canadian Patent: 2342614, Australian patent: 2373248 other patents both foreign and domestic applied for and pending. All material copyright of Balboa Water Group.
13
42135F
DIN Modules and Adapters
6’ Length
Water Level Sensor
Material No. 25404
12’ inch Length
6-Pin DIN Water Temperature & Level Sensor Material No. 25751
DIN Cables and Splitters
1’ Length to “Y”
3’ Length to “Y”
6’ Length to “Y”
6’ Length
Material No. 25569
Material No. 25748
8 Pin DIN
8 Pin DIN
8 Pin DIN
8 Pin DIN (Blower)
(Control Box)
Standard DIN Cable for Control Box or Blower Setup
Splitter Cable for Control Box and Blower Setup
With 5 Volts
Without 5 Volts
22 AWG 8’ Length
4-Pin Mini DIN Male to Lampholder Cable Assembly Material No. 25652
10’ Length
Solenoid Cable Assembly Material No. 25670
6 Inch Length
8 Foot Length
4-Pin DIN Spa Light Adapter 20 Gauge Material No. 25750
Material No. 25099
24” Length (with nut)
Material No. 32016
Sensor Assy Kit (1/4” dia.)
File Name:
Extendable Bulb Holder EFX
Titan_DIN_Cables_MASTER_11x17_2012_January 04_vo.ai
