PowerBlade PBC18 Installation Guide
85
Cable
Specifications
Table 30 lists the cable specifications for the 10/100Base-TX twisted pair
port for all AT-PB200 and AT-PB202/x Series models.
Table 30 10/100Base-TX Twisted Pair Cabling Specifications
Table 31 lists the cable specifications for the 100Base-FX fiber optic port
for all AT-PB200 and AT-PB202/x Series models when operating in full-
duplex mode.
Table 31 100Base-FX Cabling Specifications (Full-duplex)
Operating
Mode
Cable
Maximum
Distance
10Base-T Shielded or unshielded twisted
pair Category 3 or better 100 m (328 ft)
100Base-TX Shielded or unshielded twisted
pair Category 5 or better 100 m (328 ft)
Model Cable
Maximum
Distance
Maximum
Allowable Loss
Budget
AT-PB201
AT-PB202
AT-PB204
AT-PB205
AT-PB206
AT-PB207 50/125 or
62.5/125 µm
multimode 2 km (1.2 mi) 13 dB at 1310 nm
AT-PB202/1 9/125 µm
single-mode 15 km (9.3 mi) 16 dB at 1310 nm
AT-PB202/2 9/125 µm
single-mode 40 km (24.8 mi) 30 dB at 1310 nm
AT-PB202/3 9/125 µm
single-mode 70 km (43.4 mi) 37 dB at 1310 nm
AT-PB202/4 9/125 µm
single-mode
1
1. The cable can be non-dispersion-shifted, dispersion-shifted, or non-zero dispersion-shifted single-mode fiber optic cable.
100 km (62 mi) 37 dB at 1310 nm
