100Base-FX Fiber
Optic Port
Specifications
The following tables lists the technical specifications for the fiber optic
ports using 50/125 or 62.5/125 multimode or 9/125 single-mode fiber
optic cable.
Table 12 Fiber Optic Transmitter
Model Cable
Optical
Frequency
Launch Power
1
Maximum Average Minimum
AT-PB101
and
AT-PB102 50/125 µm multimode 1310 nm -14.0 dBm -20.3 dBm -22.5 dBm
62.5/125 µm
multimode 1310 nm -14.0 dBm -16.8 dBm -19.0 dBm
AT-PB103/1 9/125 µm single-mode 1310 nm -8.0 dBm -11.5 dBm -15.0 dBm
AT-PB103/2 9/125 µm single-mode 1310 nm 0.0 dBm -3.0 dBm -5.0 dBm
AT-PB103/3 9/125 µm single-mode 1310 nm 0.0 dBm -2.0 dBm -4.0 dBm
AT-PB103/4 9/125 µm single-mode 1550 nm 0.0 dBm -1.5 dBm -3.0 dBm
1. The launch power is measured at one meter from the transmitter.
Table 13 Fiber Optic Receiver
Model Fiber Optic Diameter
Optical
Frequency
Receive Power
Minimum Typical Saturation
AT-PB101
and
AT-PB102 50/125 or 62.5/125 µm
multimode 1310 nm -31.8 dBm -34.5 dBm -14.0 dBm
AT-PB103/1 9/125 µm single-mode 1310 nm -31.0 dBm -31.0 dBm -8.0 dBm
AT-PB103/2 9/125 µm single-mode 1310 nm -35.0 dBm -38.0 dBm 0.0 dBm
AT-PB103/3 9/125 µm single-mode 1310 nm -37.0 dBm -37.0 dBm -3.0 dBm
AT-PB103/4 9/125 µm single-mode 1550 nm -37.0 dBm -37.0 dBm -3.0 dBm
