PowerBlade PBC18 Installation Guide
55
Cable
Specifications
Table 5 lists the cable specifications for the 10Base-T twisted pair port for
all AT-PB10 Series modules.
Table 5 10Base-T Port Specifications
The second port on the AT-PB15 has a BNC connector with a maximum
operating distance of 185 meters (606 feet) using thinnet cabling.
Table 6 lists the cable specifications for the 10Base-F fiber optic port on
the AT-PB13 and AT-PB14 when operating in full-duplex mode.
Table 6 10Base-F Port Specification (Full-duplex)
Connector Cable
Maximum
Distance
1
1. Maximum distance can only be obtained when the UTP/STP cabling is installed and verified to TIA/EIA 568A Commercial
Building Telecommunications Cabling Standard.
RJ-45 Shielded or unshielded twisted pair
Category 3 or better 100 m (328 ft)
Model Connector Cable
Maximum
Distance
1
1. Maximum distance over Multimode Fiber (MMF) is 2 km (1.2 mi) if and only if the maximum measured optical loss budget is
less than 20 dB’s when measured at 850 nm optical wavelength.
AT-PB13 ST 50/125 µm or 62.5/125 µm
multimode 2 km (1.2 mi)
AT-PB14 SC 50/125 µm or 62.5/125 µm
multimode 2 km (1.2 mi)
