PowerBlade PBC18 Installation Guide
57
Table 7 lists the connector types and maximum distances for the
AT-PB100 Series Media Converter modules.
Table 7 AT-PB100 Series Maximum Operating Distances
Model
100Base-FX Port 100Base-TX Port
Connector
Maximum
Distance
1
1. Maximum distance for 100 Mbps Optical Datalinks are dependent on the following factors: type of optical fiber, duplex mode of
both end-nodes, and maximum optical loss budget for each of the optical fibers at the operating optical wavelength.
Connector
Maximum
Distance
2
2. Maximum distance can only be obtained when the UTP/STP cabling is installed and verified to TIA/EIA 568A Commercial
Building Telecommunications Cabling Standard.
AT-PB101 ST 2 km (1.2 mi) RJ-45 100 m
(328 ft)
AT-PB102 SC 2 km (1.2 mi) RJ-45 100 m
(328 ft)
AT-PB103/1 SC 15 km (9.3 mi) RJ-45 100 m
(328 ft)
AT-PB103/2 SC 40 km (24.8 mi) RJ-45 100 m
(328 ft)
AT-PB103/3 SC 75 km (46.5 mi) RJ-45 100 m
(328 ft)
AT-PB103/4 SC 100 km (62 mi) RJ-45 100 m
(328 ft)
